FLKS L939H Wheel Loader – Technical Specifications
The FLKS L939H Wheel Loader is a heavy-duty machine designed for material handling, loading, and earthmoving applications in construction sites, mining operations, plantations, and industrial environments.
Below is a professional English specification format suitable for a product catalog or marketing brochure. Exact technical figures should be verified against the manufacturer’s official datasheet for the L939H model.
Technical Specifications
Standard configuration — compiled from published FLKS L939H specifications. Figures may vary by configuration.
| Specification | Standard L939H | High-Dump L939H |
|---|---|---|
| Rated Load Capacity | 2,000 kg | 2,000 kg |
| Bucket Capacity | 1.1 m³ | 2.1 m³ |
| Operating Weight | 6,320 kg | 6,850 kg |
| Overall Dimensions (L × W × H) | 6,750 × 2,220 × 2,980 mm | 7,850 × 2,220 × 2,980 mm |
| Engine Model | YUN NEI / YU CHAI | YUN NEI / YU CHAI |
| Rated Engine Power | 92 / 85 kW | 92 / 85 kW |
| Tire Size | 16/70-24 | 16/70-24 |
| Wheelbase | 2,760 mm | 2,955 mm |
| Minimum Turning Radius | 5,300 mm | 5,425 mm |
| Dumping Height | 3,600 mm | 4,500 mm |
| Maximum Traction | 60 kN | 60 kN |
| Maximum Gradeability | 25° (listed) | 25° (listed) |
| Fuel Tank Capacity | 100 L (listed for L-series) | 100 L (listed for L-series) |
Sources: FLKS L939H Wheel Loader published product listings.
Key Features
-
High productivity: Designed for efficient loading and material handling.
-
Reliable performance: Hydraulic system engineered for effective power transmission.
-
Flexible operation: Articulated steering supports maneuverability in confined working areas.
-
Operator comfort: Cab design intended to reduce vibration and improve working comfort.
-
Easy maintenance: Accessible components help simplify routine servicing.
Applications
-
Construction and infrastructure projects
-
Sand, gravel, and aggregate handling
-
Plantation and agricultural operations
-
Industrial material handling
-
General earthmoving and loading work
Note: The published specifications distinguish between the standard L939H and the high-dump version. Confirm the exact configuration, engine model, bucket capacity, and dimensions with the supplier before using these figures in an official technical datasheet.
